| Feature |
Description |
| Image Sensor |
1/3" SONY Super HAD High-res |
| Effective Pixels-NTSC |
768(H)X494(V) |
| Effective Pixels-PAL |
752(H)X582(V) |
| H.Resolution-NTSC |
500 TV Lines (at Day) / 550 TV Lines (at Night) |
| H.Resolution-PAL |
490 TV Lines (at Day) / 540 TV Lines (at Night) |
| Synchronizing system |
Internal / Line lock |
| Scanning system |
NTSC 525 Lines PAL 625 Lines 2:1 Interlaced |
| Video output |
1.0Vp-p Composite. 75 Ohms |
| S/N ratio |
More than 48dB (AGC Off) |
| Min. Illumination |
0.2 Lux at F1.2 (DSS off) / 0.0001 Lux at F1.2 (DSS on) |
| BLC |
ON/OFF by OSD |
| Shutter Speed-NTSC |
1/60 to 1/100,000 sec |
| Shutter Speed-PAL |
1/50 to1/100,000 sec |
| Gamma correction |
Standard r=0.45 |
| White Balance |
2100 K to 9100 K Auto
ATW/Push Lock selectable by OSD
|
| Gain Control |
Standard : -6dB to 42dB Auto / Maximum by OSD |
| Smear Effect |
0.005% |
| Power source |
DC12V / AC24V Dual power |
| Operating current |
C/CS Mount |
| Iris Control |
ESC / Auto by slide switch |
| Operating Temperature |
14 F to 122 F (-10?C ~ +50?C) |
| Humidity |
Within 90% RH |
| Measurement (mm) |
62(W) X 58(V) X 140(L) |
| Weight (Approx.g) |
500 |
|
OSD Menu |
|
| WDR |
Auto / On / Off |
| White balance |
Atuo (ATW) / Push Lock / User selectable (Push: 1800?K~10,500?K) |
| Gain Control |
Low, Middle, High, Off Selectable |
| Shutter speed |
1/60 - 1/120,000 sec (NTSC), 1/50 - 1/100,000 sec (PAL) |
| Digital Slow Shutter
|
Off/2 x to 160 x (DSS) |
| Privacy Masking
|
On/Off (4 programmable zones) |
| Digital zoom
|
OFF, 1.5 x, 2 x, 3 x |
