| Feature |
Description |
| Image Format (1/3" Color CCD) |
1/3" SONY Super HAD High-res |
| Effective Pixels-NTSC |
768(H)X494(V) |
| Effective Pixels-PAL |
752(H)X582(V) |
| Min. Illumination |
0.03Lux at F1.2 |
| H.Resolution |
500 TV Lines |
| Synchronizing system |
Internal |
| Scanning system |
NTSC 525 Lines, PAL 625 Lines, 2:1 Interlaced |
| Video output |
1.0Vp-p Composite. 75 Ohms |
| S/N ratio |
More then 50 dB (AGC Off) |
| Back Light Compensation |
ON/OFF by Dip Switch |
| Shutter Speed-NTSC |
1/60 to 1/100,000 sec |
| Shutter Speed-PAL |
1/50 to 1/100,000 sec |
| Gamma correction |
Standard r=0.45 Switchable r=1.0 by Dip Switch |
| White Balance |
2100 K to 9100 K Automatic or Manually adjustable by Dip S/W with Up/Down Push BTN |
| Gain Control |
4dB to 30dB Auto |
| Smear Effect |
0.005% |
| MTBF |
80,000 hours |
| Lens mount |
C-Mount (17.5mm Flange back) to CS-Mount (12.5mm Flange back) & Fine focus ± 1.0mm |
| Iris Control |
Video Iris/ESC/DC Iris |
| Power source |
12VDC (Input tolerance:10V to 15V) / 130mA |
|
Dip S/W
Functions
|
|
| ESC/ALC |
O |
| BLC On/Off |
O |
| Flickerless On/Off |
O |
| Internal / Line Lock |
X |
| AWB/MWB |
X |
| Operating Temperature |
14 F to 122 F (-10?C ~ +50?C) |
| Humidity |
Within 90% RH |
| Measurement (mm) |
50(W) x 50(V) x 114.9(L) |
| Weight (Approx.g) |
310 |
|
Optional
Features
|
|
| AGC Nor/Max |
O |
| Gamma 0.45/1.0
|
O |
| True Day/Night
|
O |
| Dual Filter mechanism |
O |
| IR Sensitivity |
O |
| External Audio |
O |
|
Rear Panel
|
|
| Video Out (BNC) |
O |
| Power Indicator (Red LED) |
O |
| Power Input terminal |
O |
| Line phase push BTN |
X |
| W/B adjust push BTN |
O |
| Dip S/W |
O |
|
Side Panel
|
|
| Auto Iris jack |
O |
| Iris Mode Slide S/W |
O |
| DC Iris Level Volume |
O |
